Slot Props Vue

Props and $emit

When using Vue to develop a project, we divide the content of the project into modules, but sometimes there is data interaction between modules. In real project development, father-son and brother components need to pass values to each other. The most traditional way to pass values is props and $emit.

Vue implements a content distribution API inspired by the Web Components spec draft(opens new window), using the slotelement to serve as distribution outlets for content. This allows you to compose components like this. As you can see, this looks very similar to the render prop in our React component. Here, we are returning a default scoped slot, which passes along an object with whatever we want. Here, we give it the results and our search method. In our autocomplete component, we use the slot-scope attribute to get access to the data from the child component. This is the second part in a five-part series about the JavaScript framework, Vue.js. In this part, we'll go over Components, Props, and Slots.

I. Props

Prop is some custom features that you can register on components. When a value is passed to a prop feature, it becomes an attribute of that component instance. To pass a title to the blog component, we can include it in the list of acceptable props for the component with a props option.

1. Examples of props passing values

Different parameters can also be passed to subcomponents:

2. Pros type validation
If we want each prop to have a specified value type and list prop as an object, the names and values of these properties are prop's respective names and types.

To make passing values more flexible, vue provides the following props authentication methods:

If a requirement is not met, Vue will warn you in the browser console. This is especially helpful in developing a component that will be used by others.

Note:

• All props make a single downlink binding between their father and son props: updates to the parent prop flow downward to the child components, but not vice versa. This prevents accidental changes in the state of the parent component from the child component, resulting in incomprehensible data flow to your application.
• Note that those props are validated before a component instance is created, so the properties of the instance (such as data, computed, etc.) are not available in default or validator functions.
• Because components cannot always predict the parameters that other components will pass in when they call the current component, vue also allows components to pass in some non-props features when they are called. These features are automatically added to the root element of the component.

2. $emit

A child component is called by a parent component. When a child component triggers a function, it needs a parent component response, using $emit.

1. $emit simple example

We can also throw some data to the outside world when we throw an event.

If a component throws more than one data when throwing an event, it can continue to pass a value to $emit in the form of a parameter list, and then call it in the form of a parameter list in the parent component. But when there is a lot of data, it makes the code seem lengthy, so we recommend that all the data to be thrown be integrated into one object and passed in an object to the second parameter of the $emit function.

Slot slot slot

Slot is the second way that components are called, which improves the reusability of components.

When the child component calls the parent component and transfers its value, it tends to transfer in the data layer, but sometimes we hope that the child component can respond better to one of its parent components in the structure rendering layer, and the content of the child component can be rendered through the data control of the parent component.

If we need an operation result prompt box, the title, picture and button bar in the bullet box all render the concrete result according to the operation result. Using props or $emit can also achieve this effect, but if the results of multiple rendering are very different, then the code redundancy goes up again, so Vue provides a more concise way, that is, slots.

A slot is equivalent to encapsulating a component into a large framework. As for what and how to display it, it can transfer data when invoked, control it by data, and display the incoming content when invoked.

1. Small examples of slots

Note:
If the Alert component does not contain a < slot > element, anything between the start tag and the end tag will be discarded when the component is called.

2. Setting up backup slots for components

If a slot is reserved in a component, but the content is not distributed when the component is called, it may lead to some unpredictable errors in structure and logic, so sometimes it is necessary to set a default content for the slot.

3. Named sockets

To encapsulate a component with high reusability, a slot may not be enough. We can reserve multiple slots for each slot at different locations of the component structure, name each slot, and distribute the corresponding content to different slots when calling the component. This is the named slot.

Call the Alert component:

Abbreviation of Named Slot:

Note:

• There is no < slot > with the name attribute set, and the default name value is default.
• The v-slot attribute can only be added to one < template > (except for exclusive default slots).

4. Scope slots

Sometimes we need to access the data inside the component when we call it and distribute content to its socket. The data in the component can be bound to the slot prop, and then the data on the slot prop can be accessed at the same time when the component is called.

Call the slot and use the value of the slot prop:

Multiple slot prop s can be set for slots:

Receive:

Slot prop can also be used for deconstruction:

Note:
If there are many slot props, it is recommended to integrate all data into one object and pass one slot prop.

Render function, JSX grammar and CreaeElement function

Render functions are the same as templates in creating html templates, but in some scenarios, the code implemented with templates is tedious and repetitive, so render functions can be used.

If render function is used in component rendering, then you can not use the < template > tag. Only < script > labels and < style > labels are required in component files.

Before we understand the render function, we need to define a concept of Vnode.

1. Vnode (virtual node)

When using Vue to develop a project, the structure rendered on the browser is rendered on the browser by Vue through various conditions, loops, calculations and other operations of the underlying mechanism. We regard the final result rendered on the browser as a real DOM tree.

But Vue responds to data efficiently. Faced with such efficient data response, it is also necessary to update nodes in the page equally efficiently. However, the structure of DOM is very large and complex, and it is particularly difficult to complete all DOM updates.

For example, we render a merchandise management list. When a certain value of a commodity changes, the list rendering of the page also needs to be updated. If we want to use native JS to render, we may need to re-render the entire table, or a row. If you want to locate a cell accurately, the code is very demanding.

Fortunately, when using Vue, we don't need to update the DOM tree manually using JS. Vue provides a virtual DOM tree through which it can track how it wants to change the real DOM.

DOM nodes written in vue file and DOM in render function are virtual DOM. When browser renders, all virtual DOM will be calculated and rendered on browser finally.

When we create a virtual DOM, we include all the information of the virtual DOM, such as child elements, class names, styles, locations, and so on.

Vue instances provide render functions to render virtual DOM, and render function parameters (also a function) to create virtual DOM.

2. Example render function

The < Home > component can be called normally, and the < div > rendered by the render function is taken when it is called.

render function:

• The parameter is the ce function (which is written as createElement in many places).
• The return value is a VNode (node to be rendered).

3. Parameter of render function - createElement function

The parameter of render function is the createElement function, which creates VNode as the return value of render.

The createElement function takes three parameters:

• Parametric 1:
  String Object Function
  An HTML tag name, component option object, or resolve has one of the async functions mentioned above. Required items.
• Parametric 2:
  Object
  An object that contains all the relevant attributes of this tag (or template). Optional.
• Parametric 3:
  String Array
  A child node or list created by createElement.

Following are detailed descriptions and examples of the second and third parameters of createElement:

4. JSX grammar

If the structure in a template is relatively simple, we can use the createElement function, but once the structure is slightly more complex, the code becomes particularly lengthy.

If you want to continue using render functions, you need to use JSX grammar. Because JSX grammar allows HTML structures to be written in JS code.

JSX grammar may be more widely used in React.

Added by flyersun on Thu, 01 Aug 2019 08:48:09 +0300

Smashing Newsletter

Every week, we send out useful front-end & UX techniques. Subscribe and get the Smart Interface Design Checklists PDF delivered to your inbox.

With the recent release of Vue 2.6, the syntax for using slots has been made more succinct. This change to slots has gotten me re-interested in discovering the potential power of slots to provide reusability, new features, and clearer readability to our Vue-based projects. What are slots truly capable of?

If you’re new to Vue or haven’t seen the changes from version 2.6, read on. Probably the best resource for learning about slots is Vue’s own documentation, but I’ll try to give a rundown here.

What Are Slots?

Slots are a mechanism for Vue components that allows you to compose your components in a way other than the strict parent-child relationship. Slots give you an outlet to place content in new places or make components more generic. The best way to understand them is to see them in action. Let’s start with a simple example:

This component has a wrapper div. Let’s pretend that div is there to create a stylistic frame around its content. This component is able to be used generically to wrap a frame around any content you want. Let’s see what it looks like to use it. The frame component here refers to the component we just made above.

The content that is between the opening and closing frame tags will get inserted into the frame component where the slot is, replacing the slot tags. This is the most basic way of doing it. You can also specify default content to go into a slot simply by filling it in:

So now if we use it like this instead:

The default text of “This is the default content if nothing gets specified to go here” will show up, but if we use it as we did before, the default text will be overridden by the img tag.

Multiple/Named Slots

You can add multiple slots to a component, but if you do, all but one of them is required to have a name. If there is one without a name, it is the default slot. Here’s how you create multiple slots:

We kept the same default slot, but this time we added a slot named header where you can enter a title. You use it like this:

Just like before, if we want to add content to the default slot, just put it directly inside the titled-frame component. To add content to a named slot, though, we needed to wrap the code in a template tag with a v-slot directive. You add a colon (:) after v-slot and then write the name of the slot you want the content to be passed to. Note that v-slot is new to Vue 2.6, so if you’re using an older version, you’ll need to read the docs about the deprecated slot syntax.

Scoped Slots

One more thing you’ll need to know is that slots can pass data/functions down to their children. To demonstrate this, we’ll need a completely different example component with slots, one that’s even more contrived than the previous one: let’s sorta copy the example from the docs by creating a component that supplies the data about the current user to its slots:

This component has a property called user with details about the user. By default, the component shows the user’s last name, but note that it is using v-bind to bind the user data to the slot. With that, we can use this component to provide the user data to its descendant:

To get access to the data passed to the slot, we specify the name of the scope variable with the value of the v-slot directive.

There are a few notes to take here:

• We specified the name of default, though we don’t need to for the default slot. Instead we could just use v-slot='slotProps'.
• You don’t need to use slotProps as the name. You can call it whatever you want.
• If you’re only using a default slot, you can skip that inner template tag and put the v-slot directive directly onto the current-user tag.
• You can use object destructuring to create direct references to the scoped slot data rather than using a single variable name. In other words, you can use v-slot='{user}' instead of v-slot='slotProps' and then you can use user directly instead of slotProps.user.

Taking those notes into account, the above example can be rewritten like this:

A couple more things to keep in mind:

• You can bind more than one value with v-bind directives. So in the example, I could have done more than just user.
• You can pass functions to scoped slots too. Many libraries use this to provide reusable functional components as you’ll see later.
• v-slot has an alias of #. So instead of writing v-slot:header='data', you can write #header='data'. You can also just specify #header instead of v-slot:header when you’re not using scoped slots. As for default slots, you’ll need to specify the name of default when you use the alias. In other words, you’ll need to write #default='data' instead of #='data'.

There are a few more minor points you can learn about from the docs, but that should be enough to help you understand what we’re talking about in the rest of this article.

What Can You Do With Slots?

Slots weren’t built for a single purpose, or at least if they were, they’ve evolved way beyond that original intention to be a powerhouse tool for doing many different things.

Reusable Patterns

Components were always designed to be able to be reused, but some patterns aren’t practical to enforce with a single “normal” component because the number of props you’ll need in order to customize it can be excessive or you’d need to pass large sections of content and potentially other components through the props. Slots can be used to encompass the “outside” part of the pattern and allow other HTML and/or components to placed inside of them to customize the “inside” part, allowing the component with slots to define the pattern and the components injected into the slots to be unique.

For our first example, let’s start with something simple: a button. Imagine you and your team are using Bootstrap*. With Bootstrap, your buttons are often strapped with the base `btn` class and a class specifying the color, such as `btn-primary`. You can also add a size class, such as `btn-lg`.

* I neither encourage nor discourage you from doing this, I just needed something for my example and it’s pretty well known.

Let’s now assume, for simplicity’s sake that your app/site always uses btn-primary and btn-lg. You don’t want to always have to write all three classes on your buttons, or maybe you don’t trust a rookie to remember to do all three. In that case, you can create a component that automatically has all three of those classes, but how do you allow customization of the content? A prop isn’t practical because a button tag is allowed to have all kinds of HTML in it, so we should use a slot.

Now we can use it everywhere with whatever content you want:

Of course, you can go with something much bigger than a button. Sticking with Bootstrap, let’s look at a modal, or least the HTML part; I won’t be going into functionality… yet.

Now, let’s use this:

The above type of use case for slots is obviously very useful, but it can do even more.

Reusing Functionality

Vue components aren’t all about the HTML and CSS. They’re built with JavaScript, so they’re also about functionality. Slots can be useful for creating functionality once and using it in multiple places. Let’s go back to our modal example and add a function that closes the modal:

Now when you use this component, you can add a button to the footer that can close the modal. Normally, in the case of a Bootstrap modal, you could just add data-dismiss='modal' to a button, but we want to hide Bootstrap specific things away from the components that will be slotting into this modal component. So we pass them a function they can call and they are none the wiser about Bootstrap’s involvement:

Renderless Components

And finally, you can take what you know about using slots to pass around reusable functionality and strip practically all of the HTML and just use the slots. That’s essentially what a renderless component is: a component that provides only functionality without any HTML.

Making components truly renderless can be a little tricky because you’ll need to write render functions rather than using a template in order to remove the need for a root element, but it may not always be necessary. Let’s take a look at a simple example that does let us use a template first, though:

This is an odd example of a renderless component because it doesn’t even have any JavaScript in it. That’s mostly because we’re just creating a pre-configured reusable version of a built-in renderless function: transition.

Yup, Vue has built-in renderless components. This particular example is taken from an article on reusable transitions by Cristi Jora and shows a simple way to create a renderless component that can standardize the transitions used throughout your application. Cristi’s article goes into a lot more depth and shows some more advanced variations of reusable transitions, so I recommend checking it out.

For our other example, we’ll create a component that handles switching what is shown during the different states of a Promise: pending, successfully resolved, and failed. It’s a common pattern and while it doesn’t require a lot of code, it can muddy up a lot of your components if the logic isn’t pulled out for reusability.

So what is going on here? First, note that we are receiving a prop called promise that is a Promise. In the watch section we watch for changes to the promise and when it changes (or immediately on component creation thanks to the immediate property) we clear the state, and call then and catch on the promise, updating the state when it either finishes successfully or fails.

Then, in the template, we show a different slot based on the state. Note that we failed to keep it truly renderless because we needed a root element in order to use a template. We’re passing data and error to the relevant slot scopes as well.

And here’s an example of it being used:

We pass in somePromise to the renderless component. While we’re waiting for it to finish, we’re displaying “Working on it…” thanks to the pending slot. If it succeeds we display “Resolved:” and the resolution value. If it fails we display “Rejected:” and the error that caused the rejection. Now we no longer need to track the state of the promise within this component because that part is pulled out into its own reusable component.

So, what can we do about that span wrapping around the slots in promised.vue? To remove it, we’ll need to remove the template portion and add a render function to our component:

Slots Vs Props Vue

There isn’t anything too tricky going on here. We’re just using some if blocks to find the state and then returning the correct scoped slot (via this.$scopedSlots['SLOTNAME'](...)) and passing the relevant data to the slot scope. When you’re not using a template, you can skip using the .vue file extension by pulling the JavaScript out of the script tag and just plunking it into a .js file. This should give you a very slight performance bump when compiling those Vue files.

Vue Slot Props Computed

This example is a stripped-down and slightly tweaked version of vue-promised, which I would recommend over using the above example because they cover over some potential pitfalls. There are plenty of other great examples of renderless components out there too. Baleada is an entire library full of renderless components that provide useful functionality like this. There’s also vue-virtual-scroller for controlling the rendering of list item based on what is visible on the screen or PortalVue for “teleporting” content to completely different parts of the DOM.

I’m Out

Vue’s slots take component-based development to a whole new level, and while I’ve demonstrated a lot of great ways slots can be used, there are countless more out there. What great idea can you think of? What ways do you think slots could get an upgrade? If you have any, make sure to bring your ideas to the Vue team. God bless and happy coding.
